DAEWOO FLAT BED CNC LATHE

Please check our website for more info: DAEWOO FLAT BED CNC LATHE MODEL: PRO-TURN 602500 SN: A261208 NEW: 1995 SPECIFICATIONS: SWING OVER BED ......................
27.95 SWING OVER CARRIAGE .................
17 MAX.
TURNING DIAMETER ...............
23.62 MAX.
TURNING LENGTH .................
98.42 MAX LOAD CAPACITY ...................
5512 LBS. SPINDLE SPEED STEPS .................
AUTO 3 SPINDLE SPEEDS ......................
28-2000 RPM SPINDLE NOSE ........................
A1-11 HOLE THRU SPINDLE ...................
4 MAX LOADING CAPACITY BY CHUCK ONLY ..
1323 LBS. TURRET CONFIGURATION ................
12 TOOLS V8 H4 X-AXIS TRAVEL .......................
15 Z-AXIS TRAVEL .......................
83 RAPID TRAVERSE XZ ..................
326472 IPM TAILSTOCK TAPER .....................
MT6 TAILSTOCK QUILL .....................
4.4 TAILSTOCK QUILL MOVEMENT ............
MANUAL HOOK TYPE MAIN MOTOR ..........................
25 HP APPROX.
WEIGHT ......................
18000 LBS. EQUIPPED WITH: - FANUC 0T CNC CONTROL - 15 3-JAW CHUCK - TAILSTOCK - CHIP CONVEYOR - ALL AVAILABLE MANUALS
