Specification
Amplification
Channels: 5
Amplification Type: Direct Energy
130 Wch 6 ohms 1 kHz THD 1.0 1ch Driven
Audio Features
Dolby Atmos1 for 3.1.2chDolby Surround1
Surround Enhancer1
DTS:XDTS Neural:X
Reflex Optimizer
Dolby TrueHDDolby Digital Plus
DTS-HD Master AudioDTS-HD High Resolution AudioDTS 9624DTS-ESDTS-HD Express
DSD Disc SACD Playback via HDMI 2.8 MHz5.1ch 2ch
Digital Core Engine with Cirrus Logic Quad Core x1
384 kHz32-bit DAC AK4438
HDMI Audio Return Channel ARC
MCACC Auto Room Tuning
Phase Control
Subwoofer EQ
Advanced Sound Retriever 2ch
Advanced Surround Modes
Classical Unplugged Entertainment Show Drama Advanced Game Action RockPop Sports Extended Stereo Extended Mono Front Stage Surround Advance
Video Features
Ultra HD Pass-through with HDCP 2.2 4K60p4:4:424-bit 4K24p4:4:436-bit 4K60p4:2:036-bit
HDR10 and BT.2020 Support
Dolby Vision Compatible
Ultra HD Upscaling 1080p 4K
3D Ready Blu-ray Disc Broadcast and Games
Deep Color 36-bit x.v.Color
Home Network Features
Whole Home Audio with FlareConnect1
Chromecast built-in12
DTS Play-Fi12 Ready
Apple AirPlay Certified
Amazon Music3 Spotify4 TIDAL4 Deezer4 and Pandora4 Music-Streaming Services Ready
Internet Radio with TuneIn
Hi-Res Audio File Playback via USBNetwork
Up to 192 kHz24-bit ALAC AIFF FLAC WAV
5.62.8 MHz DSD Playback except via Wireless LAN
Dolby TrueHD Playback via USB only
Convenience Features
Built-in Wi-Fi Dual Band 5 GHz2.4 GHz
Built-in Bluetooth Wireless Technology Version: 4.1 Profile: A2DPAVRCP Codec: SBCAAC
Works with Pioneer Remote App iOSAndroid5 for Multi-room Entertainment Control and Network Streaming
Compatible with AS-DB100 USB DAB Adapter Sold Separately6
GUI with SystemNetwork Setup Menu
Auto Power Off in HDMI Standby Through
DABDAB Radio Ready optional AS-DB100 required
AMFM Tuner 40 Presets
Sleep Timer
User-Friendly Simple Remote Control
Front Terminals
USB 1 In for USB Drive
MCACC Setup MIC In
Audio 1 In Mini Stereo Jack
Phones 1 Out
Rear Terminals
HDMI 4 In 4 Assignable
HDMI 1 Out
Ethernet 1 In
USB 1 In for USB Drive
AV Composite 2 In Assignable
Digital Coaxial 1 In Assignable
Digital Optical 1 In Assignable
Subwoofer 1 Pre Out
Speaker 5 ch Out FRONT CENTER SURROUND
FMAM Antenna
Specifications
Power Requirements: AC 220-240 V 5060 Hz
Power ConsumptionStandby: 400 W0.15 W
Dimensions W x H x D: 435 x 173 x 320.5 mm
Weight: 8.6 kg
1 Available with future firmware update.
2 Compatible apps required.
3 Amazon Music which is integrated in this product is only available in U.S.
U.K.
Germany Spain Italy France and Japan.
4 Available services may differ depending on your area.
Pandora is available in Australia and New Zealand only.
5 Available for free download from the App Storethe Google Play.
6 AS-DB100 is compatible with rear-panel USB port only.
